Description

 Bobs Flagpole Company Presents The ZEUS 30' High Wind Fiberglass Flagpole Collection.
Proudly Handmade in the USA! Shipping Included 4 to 5 week delivery

SPECFICATIONS:

Introducing the Fiberglass Reinforced Composite (FRC) Ground set flagpole Model # 30XR, a robust and reliable flag display solution. This high-quality flagpole stands at a mounting height of 30', extending 3' below ground for a total length of 33'. With a substantial butt diameter of 6.75" and a top diameter of 3", this flagpole boasts a sturdy design. Weighing approximately 77 lbs., this flagpole has a total shipping weight of 153 lbs.

Crafted from fiberglass woven roving and polyester resin, this flagpole is engineered with 75% of the reinforcing fibers oriented in the axial plane to maximize stiffness and 25% in the radial plane to ensure necessary hoop strength. Load calculations adhere to AASHTO and NAAMM standards, featuring a 2:1 safety factor for 125 mph winds, unflagged, with a 1.3 gust factor.

Designed with an Entasis taper and free from vertical mold seams, this flagpole is meticulously sanded smooth and coated with a high gloss Aliphatic Polyurea coating system. This special coating offers extended UV protection and excellent weather resistance.

Presenting the Aeolus Series - Model #30XR, an exceptional flagpole tailored to meet your high-quality display needs.

Standard Fittings:
30' Above Grade Height 6" Gold Anodized Ball 60' of #10 Polyester Halyard
33' Overall Height Cast FG Revolving Truck 16" Flash Collar Location:
Top Diameter - 3" 1 pair of Brass Snaps, 8.5" Nylon Cleat
Butt Diameter - 6.75" 1 pair of vinyl Snap covers, 3'x8" Ground Sleeve

Benefits of Fiberglass Composites

• Lightweight
• Easy to install
• UV & salt resistant coating ”“ dual part polyurea aliphatic paint system
• Non-conductive
• Finish does not pit or stain even when exposed to landscape materials like mulch
• Corrosion resistant

• Superior strength to weight ratio provided by layered construction of materials
• Excellent structural strength when compared to wood, metal alloys, and others.
• Available in a variety of standard colors; white, black, bronze, Faux-Luminum & Dynamic Bronze
• Custom colors are also available upon request
• Our unique manufacturing process allows for custom projects

• Sound absorbing properties: perfect for homeowners, schools, office buildings, hospitals and anywhere you do not want that annoying pinging sound of the flag snaps

• Easy to Clean & virtually maintenance free
• Best warranty in the fiberglass flagpole industry ”“ with 50 years of experience to back it, the makers of Zeus flagpoles confidently offers the best fiberglass flagpole warranty.
• Hand-crafted in Fitzwilliam, NH.   These are not machine made or mass produced providing you exceptional quality and attention to detail.

• Available in sizes 15”™ ”“ 100”™ to suit your location.
• Available in different series that are windspeed specific to complement your location.
• Fiberglass is not harmful to the environment, it can be repurposed into other usable items or recycled
